Operating instructions
A symbol of audacity and innovation in the world of Haute Horlogerie, blending technological advances with ancestral craftsmanship.
Clean lines and slender proportions shape the dynamically contoured case silhouette with sculpted lugs, while the fluted bezel and seamlessly integrated FKM rubber strap combine sporty resilience with timeless elegance.
Description
Clean lines and slender proportions shape the dynamically contoured case silhouette with sculpted lugs, while the fluted bezel and seamlessly integrated FKM rubber strap combine sporty resilience with timeless elegance.
349 €
Join waitlist
Available from October 1
Made to last.
Technical Details
- Case material
- 316L stainless steel (polished / brushed)
- Movement
- Seiko TMI NH35 with date
- Case diameter
- Ø 40 mm
- Height including crystal
- 11.90 mm
- Crystal
- High-purity sapphire crystal with anti-reflective coating
- Water resistance
- 10 ATM ≈ 100 m
- Strap
- FKM fluororubber strap with quick release
- Clasp
- 316L stainless steel double folding clasp with spring mechanism
- Lug width
- 20 mm
- Caseback
- 316L stainless steel | 6-screw caseback
- Weight
- 109 g
- Crown
- Screw-down
- Lug to lug
- 48,9 mm
ELYSEE Heritage operating instructions
2
Contents
All pages at a glance.
40 mm · stainless steel · sapphire crystal · 10 ATM
3
The watch
ELYSEE Heritage
The Heritage combines ELYSEE design language since 1960 with a reliable mechanical automatic movement. Sapphire crystal, a fluted bezel and a 40 mm stainless steel case define its presence.
The Seiko TMI NH35 automatic caliber winds itself while being worn and can also be wound by hand when needed.
Unscrew the crown, turn clockwise
4
Functions
First steps
A mechanical automatic watch should be wound before first wear. Unscrew the screw-down crown counterclockwise and turn it clockwise several times until the seconds hand starts moving.
While worn, the mainspring is then wound automatically by movement on the wrist.
Display and controls
5
Overview
Reading the dial.
- 1Hour handShows the current hour.
- 2Minute handShows the minutes precisely on the scale.
- 3Seconds handRuns mechanically and stops while setting.
- 4Date windowDate display at six oclock.
- 5Screw-down crownFor hand winding, date, time and water resistance.
0 · 1 · 2 · 3
6
Settings
The four positions.
0 Screwed downOnly when firmly screwed down is the watch water resistant to 10 ATM.
1 Home positionHand winding clockwise, only when needed.
2 DateFirst click position for the date display.
3 TimeSecond click position; the seconds hand stops.
The crown is screw-down. Unscrew it before every adjustment and screw it down firmly again afterwards.
7
Time & Date
Set it correctly.
- 1UnscrewUnscrew the crown counterclockwise.
- 2Set the datePull the crown to position 2 and turn clockwise to set the previous days date.
- 3Set the timePull the crown to position 3. The seconds hand stops. Set the exact time and note the date change at midnight.
- 4Screw downPress the crown in and screw it down clockwise again.
Do not set the date between 9 p.m. and 4 a.m. During this period the movement is switching the date, and correction can damage it.
10 ATM · stainless steel · sapphire crystal
8
Care
Caring for your ELYSEE.
Never pull or turn the crown while the watch is wet and always keep it firmly screwed down. This is essential for water resistance.
Do not hold the watch under running tap water and do not wear it in a sauna or hot bath. After contact with salt water, rinse it with clear fresh water.
Keep it away from strong magnetic fields and maintain at least 5 cm distance from speakers, tablet covers and magnetic clasps.
10 ATM water resistanceSuitable for swimming and snorkeling. Not suitable for scuba diving.
Detail in focus
The impossible becomes possible
THERE ARE MOMENTS WHEN TIME IS NOT MEASURED BUT EXPERIENCED. THE HERITAGE ACCOMPANIES YOU FROM THE FIRST MORNING LIGHT TO THE HOURS THAT LAST LONGER THAN PLANNED. ON THE WRIST IT FEELS FAMILIAR AND AWAKENS THE DESIRE TO SET OUT AGAIN. A WATCH FOR MEMORIES STILL WAITING TO BE MADE.
Clear at a glance.
The structured dial combines clear contrast with precisely placed indices. Every line is designed to make the time quick and effortless to read.
Monobloc case
Milled from a solid block.
The Heritage case body is precisely milled from a solid block of 316L stainless steel. This creates the case body and lugs as a single, contiguous monobloc form. Polished and brushed surfaces highlight the milled contours.
Timeless Mechanics
Elegance redefined
Adapts to your daily life
Effortlessly well-dressed
01
02
Only 11.9 mm
Thanks to the precise interplay of design and engineering, the Heritage achieves an industry-leading slim silhouette.
Super-LumiNova® BGW9
Readable when it gets dark.
Hands and indexes coated with Super-LumiNova® BGW9 charge up in daylight or artificial light. If the ambient light diminishes, the time remains clearly visible.
Mechanics inside
A movement that lives with you.
The Seiko TMI NH35 winds itself through movement on the wrist. No battery, no daily ritual: its robust mechanics are made for everyday use and can also be wound by hand when needed.
Automatic
Date display
41+ hours
Power reserve
Fully wound, the watch keeps running overnight and well into the next day.
21,600 A/h
Steady beat
Six half-oscillations per second give the second hand its mechanical character.
Hacking seconds
Precise setting
When the crown is pulled out, the second hand stops, allowing the watch to be set precisely.
24 jewels
Reduced friction
Synthetic jewels reduce friction at stressed points in the movement for long-term durability.
FKM fluoro-rubber
Strong in everyday use.
FKM fluoro-rubber feels comfortable, keeps its shape and resists sweat, UV light and many everyday substances significantly better than conventional silicone.
Strap
FKM fluororubber strap with quick release
200 °C+
Dimensionally stable in heat.
Depending on the compound, FKM remains dimensionally stable even at temperatures exceeding 200 °C.
Everyday use
Resistant to more.
Sweat, sunscreen, oils, and cleaning agents attack FKM significantly less than many other elastomers.
UV + Ozone
Color that lasts.
The strap hardly fades, does not become brittle, and ages more slowly than classic rubber or silicone.
Premium comfort
Velvety. Flexible. Clean.
The surface feels high-quality, isn't sticky, and can usually be cleaned with water and a little soap.
Strap color
Individually combined
The strap makes the difference.
Choose the color that suits your watch and your everyday life. The watch body remains unchanged while the strap changes directly in the view.
Strap color
Black
20mm FKM Fluoroelastomer Watch Strap Black
€99
Sold out
Blue
20mm FKM Fluoro Rubber Watch Strap Blue
€99
Sold out
10 ATM · pressure rating according to DIN 8310
Water resistance, clearly explained.
The ATM rating describes tested static pressure in new condition. According to DIN 8310, the Heritage is rated at 10 ATM for everyday water contact, swimming and surface snorkeling. The rating is not a real diving depth and is not a permanent property.
0
ATM
5 m
Splash water
Resistant to sweat, water drops, rain and brief splashes. Not suitable for showering, bathing or swimming.
- 5 m Splash water
- 10 m Bathing and showering
- 20 m Swimming
Quality check in Düsseldorf
Released only after the final check.
Before a Heritage reaches you, it is checked once more in Düsseldorf: finishing, operation, strap, crown and the overall impression on the wrist. No watch leaves the service area before it feels right.
Final inspection
in Düsseldorf
Visual inspection
Case, crystal, dial, hands and strap are checked for a clean overall impression.
Function
Crown, date, winding and hand movement must operate precisely and consistently.
Water resistance
The screw-down crown and relevant sealing points are checked for everyday use.
Release
Only after cleaning, inspection and secure packing is the watch prepared for shipment.
Perfection from every angle Screw-down precision, down to the last detail.
Specifications
Case
Dimensions and Materials
Clear proportions and durable materials for a watch that wants to be worn daily.
- Case material
- 316L stainless steel (polished / brushed)
- Case diameter
- Ø 40 mm
- Height
- 11.90 mm
- Weight
- 109 g
- Water resistance
- 10 ATM ≈ 100 m
- Crown
- Screw-down
- Lug to lug
- 48,9 mm
Strap
Secure on the wrist
The strap combines comfortable wear with a quick, uncomplicated change.
- Strap
- FKM fluororubber strap with quick release
- Lug width
- 20 mm
- Clasp
- 316L stainless steel double folding clasp with spring mechanism
Protection and Function
Built for everyday life
- Crystal
- High-purity sapphire crystal with anti-reflective coating
- Function
- Date
- Caseback
- 316L stainless steel | 6-screw caseback
Automatic movement
Seiko TMI NH35
A proven mechanical automatic movement with hand-winding and hacking seconds. It works without a battery and is powered by movement on the wrist.
- Movement
- Seiko TMI NH35 with date
- Winding
- Automatic and manual
- Hacking seconds
- Yes
- Power reserve
- approx. 41 hours
Shipping
Safely on the way to you
We ship your order carefully and securely packaged. The estimated delivery time will be shown at checkout.
Return
30 days to decide at your leisure
You can return your unworn watch free of charge within 30 days.
Warranty
24 months covered
From the date of purchase, your ELYSEE watch is covered by a 24-month manufacturer's warranty.
- Manufacturer's warranty
- 24 months
Operating instructions
How to use your Heritage.
Mechanical watch, screw-down crown, 10 ATM water resistance: these instructions show the key steps as compact HTML pages directly in the shop.
Operating instructions
2
Contents
All pages at a glance.
40 mm · stainless steel · sapphire crystal · 10 ATM
3
The watch
ELYSEE Heritage
The Heritage combines ELYSEE design language since 1960 with a reliable mechanical automatic movement. Sapphire crystal, a fluted bezel and a 40 mm stainless steel case define its presence.
The Seiko TMI NH35 automatic caliber winds itself while being worn and can also be wound by hand when needed.
Unscrew the crown, turn clockwise
4
Functions
First steps
A mechanical automatic watch should be wound before first wear. Unscrew the screw-down crown counterclockwise and turn it clockwise several times until the seconds hand starts moving.
While worn, the mainspring is then wound automatically by movement on the wrist.
Display and controls
5
Overview
Reading the dial.
- 1Hour handShows the current hour.
- 2Minute handShows the minutes precisely on the scale.
- 3Seconds handRuns mechanically and stops while setting.
- 4Date windowDate display at six oclock.
- 5Screw-down crownFor hand winding, date, time and water resistance.
0 · 1 · 2 · 3
6
Settings
The four positions.
0 Screwed downOnly when firmly screwed down is the watch water resistant to 10 ATM.
1 Home positionHand winding clockwise, only when needed.
2 DateFirst click position for the date display.
3 TimeSecond click position; the seconds hand stops.
The crown is screw-down. Unscrew it before every adjustment and screw it down firmly again afterwards.
7
Time & Date
Set it correctly.
- 1UnscrewUnscrew the crown counterclockwise.
- 2Set the datePull the crown to position 2 and turn clockwise to set the previous days date.
- 3Set the timePull the crown to position 3. The seconds hand stops. Set the exact time and note the date change at midnight.
- 4Screw downPress the crown in and screw it down clockwise again.
Do not set the date between 9 p.m. and 4 a.m. During this period the movement is switching the date, and correction can damage it.
10 ATM · stainless steel · sapphire crystal
8
Care
Caring for your ELYSEE.
Never pull or turn the crown while the watch is wet and always keep it firmly screwed down. This is essential for water resistance.
Do not hold the watch under running tap water and do not wear it in a sauna or hot bath. After contact with salt water, rinse it with clear fresh water.
Keep it away from strong magnetic fields and maintain at least 5 cm distance from speakers, tablet covers and magnetic clasps.
10 ATM water resistanceSuitable for swimming and snorkeling. Not suitable for scuba diving.
Good to know
Frequently asked questions
<p>Answers to the questions we hear most often about the company, watches, orders and service.</p>
Still have a question? Write to us
Where is ELYSEE Watches GmbH based?
<p>ELYSEE is based in Düsseldorf. Product development, sales and service come together at our headquarters, keeping us close to our watches and to our customers.</p>
How does an automatic watch work?
<p>An automatic watch draws its energy from movement on the wrist. A rotor winds the mainspring of the mechanical movement. If the watch is not worn for a longer period, it may stop and can then be restarted through the crown or by movement.</p>
How long does the warranty last?
<p>ELYSEE watches come with a 24-month manufacturer warranty. You can find the exact terms and warranty instructions in the documents supplied with your watch or directly through our service team.</p>
Can I return my order?
<p>Orders placed through our online store can be returned within 30 days. Items should be complete and in the condition in which you received them. Please use our returns portal to start the process.</p>
When will my order be delivered?
<p>The currently expected delivery time is shown on the product page and during checkout. Once your order has shipped, you will receive a shipping confirmation with the available tracking information.</p>
What does the ATM rating mean?
<p>The ATM rating describes the tested water resistance of a model under laboratory conditions. Actual use depends on the stated rating. Water resistance is not a permanent property; seals should be checked regularly, especially before intensive water use.</p>
Can I change the strap myself?
<p>Many ELYSEE straps use a quick-release system and can be changed without tools. Please check the lug width and strap system of your model. If you are unsure, our service team will be happy to help.</p>
Where can I have my ELYSEE watch serviced or repaired?
<p>Our in-house service in Düsseldorf is your contact for inspection, maintenance and repair. Send us a short description of the issue and, if possible, photos so we can coordinate the next step with you.</p>
